The world's first double function keyboard!
Majestouch MINILA is the Mini layout version of Majestouch and we've made it as compact as possible by sharing Function keys with other keys.
It has the same key pitch as our famous Majestouch keyboards.
The most striking feature of MINILA is the "Double Function keys" located each side of the spacebar.
We focused on less frequently used finger, the thumb, and let it work with Function keys.
Just keep your thumbs busy and you get a lot of work done much easier than a normal keyboard!
You can use whichever thumb you want.
This keyboard can work well for anybody!
Professionals, intermediate or even beginner class!
Once you get used to typing on MINILA, you will not want to go back typing on normal keyboards!
[Right of design pending]
You can type cursor keys with a combination of FN key.
Pressing FN key and E/S/D/F simultaneously corresponds to ↑/←/↓/→ respectively.
With this solution, you can keep your home position and still you get to type arrows very easily.
Pressing FN key plus [:;] key simultaneously functions as backspace.
This will allow you to command backspace without changing your home position.
Those combinations will offer you a faster typing environment.
Cherry MX Brown Switch :
Known as tactile, there is a very soft click as you reach the contact point.
With the light pressure spring, it makes typing action easy, fast and stress free.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.
Cherry MX Black Switch :
Known as linear - you don't feel clicking when pressing down.
Just a smooth action.
It has characteristics that the stress transfers with proportional linearity.
You need a certain pressure to press down however it doesn't have to reach the contact point to be recognized by using repelling force.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.
Cherry MX Blue Switch :
Known as tactile feel.
You can enjoy clicking with an audible click and a tactile feel.
The key switch has gold plated contacts which make the contact even with a small force once it is typed.
It has a characteristics that makes mechanical clicking sounds.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.
Cherry MX Red Switch :
Cherry MX red has got the same feature of Cherry MX black switch.
They are linear type which makes no clicking sounds. Spring pressure is only up to 45g so that it provides you a smooth light typing feel!
DIP switch is located on the back of the keyboard for setting key codes.
The factory default setting is OFF.
There is a USB 2.0 hub built into the keyboard the edge that lets you plug in mouse, memory and so on.
| FFKB68M/UKB FFKB68ML/UKB FFKB68MC/UKB FFKB68MRL/UKB |
|
|---|---|
| Number of keys | 68 keys/UK layout key arrangement |
| Key switch | FFKB68M/UKB : Cherry MX Brown Switch (tactile feel) FFKB68ML/UKB : Cherry MX Black Switch (linear) FFKB68MC/UKB : Cherry MX Blue Switch (click tactile) FFKB68MRL/UKB : Cherry MX Red Switch (linear) |
| Key pitch/Key stroke | 19mm/4 ±0.5mm |
| Dimensions/Weight | W297xD124xH40mm (46mm raised up by stand)/680g |
| Interface | USB |
| Accessories | USB cable(1.8m)/FILCO key puller/Key caps for replacement |
| Notices | All our FILCO Keyboard have already passed the CE, FCC and RoHS certification. |
 |
|
| FFKB68M/UKB FFKB68ML/UKB FFKB68MC/UKB FFKB68MRL/UKB |
|
|---|---|
| Number of keys | 104 keys/US ASCII key arrangement |
| Key switch | FFKB68M/UKB : Cherry MX Brown Switch (tactile feel) FFKB68ML/UKB : Cherry MX Black Switch (linear) FFKB68MC/UKB : Cherry MX Blue Switch (click tactile) FFKB68MRL/UKB : Cherry MX Red Switch (linear) |
| Key pitch/Key stroke | 19mm/4 ±0.5mm |
| Dimensions/Weight | W297xD124xH40mm (46mm raised up by stand)/680g |
| Interface | USB |
| Accessories | USB cable(1.8m)/FILCO key puller/Key caps for replacement |
| Notices | All our FILCO Keyboard have already passed the CE, FCC and RoHS certification. |
